Summary
A carbon zinc "super extra heavy duty" cell with the label, outer steel casing, and top cap removed. The outer metal is zinc. It dissolves to make electrons. The electrons pass through the circuit into the carbon rod in the center, where the manganese dioxide (the black powder) absorbs them.
Copyright status:
Public domain
Source:
My brother's battery and my picture
